Alternator Rectifier 120mm OD 50A 8 Diode Bosch ADE Isuzu MAN Scania Volvo RCT1010
Vehicle Compatibility
- ADE 352/352N/352T
- ADE 354N/354T
- ADE 366N/366T
- ADE 407/407D/407H/407HT/407N/407T/407TI
- ADE 409/409N
- ADE 422/422D/422N/422T/422TI
- ADE 423N
- ADE 442N/442T
- ADE 447C/447N/447T
- BELL B20B
- BENFRA
- CUMMINS
- DAF 85.360 ATI
- DAF 95.430 ATI
- DAF 95XF 380/430/480/530
- DEUTZ
- ERF
- FAUN
- FIAT-ALLIS
- FIAT-HITACHI
- FLLR-P (F2000 19T)
- FORD CARGO
- HANOMAG
- IKARUS
- INTERNATIONAL HARVESTER
- ISUZU F-SERIES 6.0L WITH ADE ENGINE
- ISUZU F5000(FN) – WITH ADE366N ENGINE
- ISUZU F6500(FN) – WITH ADE366N ENGINE
- ISUZU F8000D(FN) – WITH ADE366N ENGINE
- ISUZU F8000D/N – WITH ADE352 ENGINE
- ISUZU F8000T – WITH ADE352T ENGINE
- ISUZU F9000 FT – WITH ADE366T ENGINE
- ISUZU F9000 TT – WITH ADE352T ENGINE
- ISUZU FTR49L 5.6 – WITH ADE352T ENGINE
- IVECO 4.0L/5.5L/5.8L/5.9L/6.0L
- IVECO 60E/65E/75E/80E/85E/95E/100E/120E/130E/150E/160E/170E/180E/315/316
- IVECO EUROCARGO 75 E14/E15
- IVECO EUROCARGO 95 E21
- IVECO EUROCARGO 130 E18
- IVECO EUROCARGO 150 E18/E21
- IVECO EUROCARGO 170 E27
- IVECO EUROCARGO 260 E27
- IVECO EUROCARGO 320 E27
- IVECO EUROTECH 440 E42
- IVECO EUROTRAKKER 330 E37
- IVECO EUROTRAKKER 380 E37/E42
- IVECO EUROTRAKKER 410 E37
- IVECO EUROTRAKKER 440 E42
- IVECO EUROTRAKKER 720 E37
- IVECO TURBOSTAR
- KHD
- KHD CRANE
- KHD LOADER
- KHD TRUCK
- LANCIA
- LAVERDIA
- LEYLAND
- LIEBHERR
- LORRAINE
- MAN (applications list supplied)
- MERCEDES-BENZ (applications list supplied)
- NISSAN
- PERKINS
- POWERSTAR
- SCANIA (bus and truck applications list supplied)
- SSANGYONG
- STEYR PINZGAUER TURBO DIESEL
- TAMROCK 1250 (PLAXTON)
- TOYOTA HINO (applications list supplied)
- UNIC
- VOLVO (applications list supplied)
Confirm by alternator label and plug style before ordering.
Specifications
- Outer Diameter: 120 mm
- Current Strength: 50 A
- Diode Type: Avalanche Diode
- Number of Diodes: 8
- Manufacturer: Bosch
- Type: IR/EF (Internal Regulator, External Fan)
- Additional parts information (as provided): 125 mm OD, 11 diode (incl trio diodes)
OE Numbers
- DAF: 1311304
- Iveco: 93160252
- MAN: 81261090018
- Mercedes-Benz: 0011540716
- Mercedes-Benz: 0011541016
- Renault: 5010844263
- Scania: 1387615
- Volvo: 3090260
- Volvo: 3090262
- Volvo: 68132
- Volvo: 11704308
Features
- Alternator rectifier for Bosch applications listed
- 120 mm outer diameter rectifier assembly
- 50A rated current strength (as provided)
- Avalanche diode type for charging circuit protection characteristics
- IR/EF configuration (internal regulator, external fan) as supplied
Why Buy From Us
- Workshop-friendly support for alternator identification and matching
- Fast nationwide courier delivery across South Africa
- Quality-checked automotive electrical components
Trusted by thousands of South African drivers for quality and durability.
Installation & Maintenance Tips
- Confirm by alternator label and plug style before ordering.
- Disconnect batteries and isolate the charging circuit before alternator strip-down.
- Measure rectifier OD on the alternator and confirm diode count/type against the unit being repaired.
- Inspect stator leads, insulators, and heat damage before fitting the new rectifier.
- After installation, load-test the charging system and verify stable output under electrical load.
